Support A2 and NICAM728 mono and stereo audio, up to dual channels
Audio options available:
- Mono L, Mono R, Mono L+R
- A2 Dual Mono (L, R), A2 Stereo
- NICAM Dual Mono (L, R), NICAM Stereo
Knowledge about A2 and NICAM 728 audio:
NICAM 728: It is transmission of two-channel digital sound with terrestrial television systems B, G, H, l, K1 and L
A2 Stereo: Known as “two-channel sound”, it is an analog television sound transmission system used in Germany, Austria, Australia, Switzerland, Netherlands and some other countries that use or used PAL-B or PAL-G. .It relies on two separate FM carriers.
Support Multiple-modulation Standard
32 (or 16/48/64) standard PAL or NTSC or SECAM TV programs output via 32 (or 16/48/64) non-adjacent or adjacent carriers output within 400MHz
Other Key Features
Support to convert 32 (or 16/48/64) IP channels (or 4 HDMI/AV+28 IP channels, or 8 HDMI/AV+24 IP channels) to analog RF out
Suport CC/Subtitle/Teletext
Support BISS De-scrambling
Support program info modify, multiple audio select l
2 (or 4) GE ports for IP MPTS/SPTS input, Max 840Mbps for each GE input
Support HEVC/H.265, H.264/AVC, MPEG-2 TS Decoding
32 (or 16/48/64) standard PAL or NTSC or SECAM TV programs output via 32 (or 16/48/64) non-adjacent or adjacent carriers output within 400MHz
Redundancy power supply for option
Compact body, Freight saving
Support Web-based Network management
